N500L-AM2C-DD

Dual-port 1G copper NIC

N500L-AM2C-DD is a dual-port 1G NIC with PCIe Gen2.0x4 host interface independently developed by MUCSE.It employs N500L-AM2 chip developed by MUCSE and integrates 1000BASE-T PHY inside.Support dual-port 1000BASE-T/100BASE-TX/10BASE-T application .

N500L-AM2C-DD NIC supports network protocol hardware acceleration,RSS,virtual SR-IOV application、NC-SI sideband management、PXE remote network startup.

Specifications

Control chip

MUCSE N500L-AM2，BGA256,17x17mm
Connecting finger

PCIe Gen2.0×4
Interface type

2×RJ45
LED

Each SFP+ provides 2 LED lights,respectively representing the Speed and Link/Activity status;

LED Status Description
Speed
Green Yellow
1Gbps:the green is always light
100M:the yellow is always light
10M:light off

LINK/ACT
Green
LINK：always light
ACT：flicker
No connection:light off
Bypass

None
Radiator

1xPassive radiator
Typical power consumption

5W
Size

134.7mm*68.9mm
Environment temperature

Operating temperature：0～50
Storage temperature：-40～85℃
Relative humidity

5%～95%RH without condensation
OS

Supports Linux kernel version 2.6 and above;support Windows
Security

Meet UL/CCC and other internationally recognized electrical product safety certifications.
Meet international electromagnetic compatibility standard Class A specifications
Safety meets GB4943 requirements
Vibration and drop tests meet the requirements of GB/T9813
Environmental requirements

Meet RoHS2.0 specifications

Physical environment
